شاشة تعمل باللمس بالسعة مقاس 7 بوصات 1024 × 600 ، IIC G + G 5 نقاط
WTY070144A20
شاشة تعمل باللمس بالسعة مقاس 7 بوصات 1024 × 600 ، IIC G + G 5 نقاط
Size:
7" Diagonal | 1024x600 Pixels
IC chip
GT911
Touchscreen:
Capacitive with I2C Interface
Structure
Glass + Glass (G + G)
Touch type
Capacitive
Surface Hardness
6H
Light Transmittance
>85%
Product Details
<فئة H2 = نمط WP-block-heading" = "حجم الخط: 30 بكسل" >7 بوصة 1024x600 ميزات شاشة تعمل باللمس بالسعة:
فوائد شاشة تعمل باللمس بالسعة مقاس 7 بوصات 1024x600
لماذا تختار Wanty؟
Technical Parameters:
|
Model
|
WTY070144A20
|
|
Size
|
7 inches
|
|
Interface
|
IIC (I2C)
|
|
Structure
|
G+G
|
|
IC Chip
|
GT911
|
|
Resolution
|
1024×600, 800×480
|
|
Hardness
|
6H
|
|
Transparency
|
≥82%
|
|
Aspect Ratio
|
16:9
|
|
Working Voltage
|
2.8V-3.3V
|
|
Touch Points
|
5 points
|
|
Viewing Area (mm)
|
152.60*86.52
|
|
Outline Dimension (mm)
|
200.00*115.00
|
|
Operating Temperature
|
-20ºC~+70ºC
|
|
Storage Temperature
|
-30ºC~+80ºC
|
|
Support System
|
Windows, Android, Linux etc
|
|
Application Fields
|
Industrial Control, Home Automation, Medical Device, Self-service Terminal etc
|
7 Inch 1024x600 Capacitive Touch Screen Customization Solution
Resolution Customization
Wanty has the options of higher resolutions including 1024×600 for use in applications offering clearer images and more display on-screen.
Touch Accuracy and Sensitivity
Another aspect of actual contact can be touched accuracy and sensitivity what again can be easily changed by Wanty in its new offer depending on the user requirement.
Driver IC Selection
Similar to the modes of other products, enable the customers to decide on the compatible driver ICs based on the physical and software interfacing of the project.
Multi-Touch Gesture Customization
Wanty support of some touch gestures such as pinch to zoom, the application rotation support or some other application based touch gestures due to the support of the certain touch controller which in turn improves the tangible touch feel for some applications.
