شاشة تعمل باللمس 800x480
WTY070144A15LM
شاشة تعمل باللمس 800x480
Production State
In Production
Stock Quantity
10 Pieces
Product Details
الميزات الرئيسية لشاشة اللمس 800 × 480:
<فئة H3 = "WP-block-heading" النمط = "حجم الخط: 23 بكسل">مزايا شاشة اللمس 800x480 أكثر قيمة:لماذا تختار Wanty؟
Technical Parameters
|
Model
|
WTY070144A15LM
|
|
Size
|
7 inches
|
|
LCD Type
|
TFT
|
|
Display Type
|
TN
|
|
Interface
|
RGB
|
|
Pin No.
|
50Pin
|
|
Resolution
|
800×480
|
|
Brightness
|
450cd/m2
|
|
Viewing Angle Range
|
70/70/50/70Deg.
|
|
Contrast Ratio
|
500:1
|
|
LCD Active Area (mm)
|
154.08×85.92
|
|
LCD Outline Dimension (mm)
|
164.90×100.00×5.70
|
|
Touch Type
|
Capacitive
|
|
Touch Points
|
5 points
|
|
Touch IC Chip
|
GT911
|
|
Touch Structure
|
G+G
|
|
Touch Interface
|
IIC (I2C)
|
|
Touch Hardness
|
6H
|
|
Operating Temperature
|
-20ºC~+70ºC
|
|
Storage Temperature
|
-30ºC~+80ºC
|
|
Bonding Method
|
Optical Bonding, Air Bonding
|
|
Support System
|
Windows, Android, Linux etc
|
|
Application Fields
|
Industrial Control, Home Automation, Medical Device, Self-service Terminal etc
|
LCD Cable Customization
To enhance the look of your cables let us know the length, position, and the pinout of your cables we will make it lively. Wanty to adapt a cable solution that will suit your needs in a way that your connection will always be sound.
LCD Interface Customization
The Custom LCD Interface Solutions for Streamlined Performance are provided by Wanty. So it is now possible to Maximize Your Design Potential with the addition of HDMI, USB, SPI, VGA and virtually any desired input/output.
Panel Type
Wanty is here to give you a dreamy panel as per your specifications. Glossy panels give it a shinier look and the picture displayed will be much more alive and vibrant. Anti-glare panels are less reflective, and hence appear easily viewable and easily readable in places that are brightly lit. So it is for you to decide as to which one of them you would like to avail from us in its customized for
Brightness Power
Do you require more or lesser brightness? Wanty is here to give you the higher nit rating for high brightness according to your requirement.
